MCP14A0155-E/SN

MCP14A0155-E/SN Overview

This product is manufactured by Microchip. MOSFET Gate Drivers This device belongs to the Inverting, Non-Inverting type. The product can operate at a maximum temperature of SMD/SMT. SOIC-8 package/case type is utilized by this product. 2 Output is the number of outputs provided by this product. Output current: 1.5 A Rise Time is 14 ns. 13 ns fall time Supply Voltage - Min: 4.5 V Supply Voltage - Max: 18 V The minimum operating temperature of this product is - 40 C. The product can operate at a maximum temperature of + 125 C. Tube packaging for easy dispensing The height of the product is 1.75 mm. 4.9 mm long Microchip Technology is a trusted brand for quality electronics This product does not have a No Shutdown feature, ensuring continuous operation. Gate Drivers product type 100 of 100 PMIC - Power Management ICs as subcategory

MCP14A0155-E/SN Image

MCP14A0155-E/SN Specifications

• Manufacturer: Microchip
• Product Category: Gate Drivers
• RoHS: Y
• Product: MOSFET Gate Drivers
• Type: Inverting, Non-Inverting
• Mounting Style: SMD/SMT
• Package / Case: SOIC-8
• Number of Drivers: 2 Driver
• Number of Outputs: 2 Output
• Output Current: 1.5 A
• Rise Time: 14 ns
• Fall Time: 13 ns
• Supply Voltage - Min: 4.5 V
• Supply Voltage - Max: 18 V
• Operating Supply Current: 750 uA
• Minimum Operating Temperature: - 40 C
• Maximum Operating Temperature: + 125 C
• Series: MCP14A0155
• Packaging: Tube
• Height: 1.75 mm
• Length: 4.9 mm
• Technology: Si
• Width: 3.9 mm
• Brand: Microchip Technology
• Shutdown: No Shutdown
• Product Type: Gate Drivers
• Factory Pack Quantity: 100
• Subcategory: PMIC - Power Management ICs
