AD7298-1BCPZ Overview

Product belongs to the AD7298-1 series. This product is categorized as Analog to Digital Converters Type: S/H ADC Tray Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style LFCSP-20 The Single Ended for this product is CMOS/TTL. Operational temperature range: -40°C ~ 125°C Number of channels: 8 Channel Supplier device package: 20-LFCSP-WQ (4x4) This product's 1M. Data-Interface: SPI, DSP 10 bits The Voltage-Supply-Analog is 2.8 V ~ 3.6 V. The Voltage Supply Digital for this product is 2.8 V ~ 3.6 V. Configuration MUX-S/H-ADC The architecture of this product is SAR . External, Internal is the reference type. 1 units Power-off control: 23 mW Maximum operating temperature of + 125 C Minimum operating temperature: - 40 C Serial 4-Wire SPI interface type Signal-to-Noise Ratio of 61.5 dB The +/- 1 LSB of this product is 0.2%. Number-of-Converters: 1 Converter 1 MS/s Sampling Rate Integral Nonlinearity: +/- 0.5 LSB Differential nonlinearity: +/- 0.5 LSB

AD7298-1BCPZ Image

AD7298-1BCPZ Specifications

• Manufacturer Analog Devices Inc.
• Product Category Data Acquisition - Analog to Digital Converters (ADC)
• Series AD7298-1
• Product Analog to Digital Converters
• Type S/H ADC
• Packaging Tray Alternate Packaging
• Mounting-Style SMD/SMT
• Package-Case LFCSP-20
• Input-Type Single Ended
• Operating-Temperature -40°C ~ 125°C
• Features Temperature Sensor
• Number-of-Channels 8 Channel
• Supplier-Device-Package 20-LFCSP-WQ (4x4)
• Sampling-Rate-Per-Second 1M
• Data-Interface SPI, DSP
• Number-of-Bits 10
• Voltage-Supply-Analog 2.8 V ~ 3.6 V
• Voltage-Supply-Digital 2.8 V ~ 3.6 V
• Configuration MUX-S/H-ADC
• Architecture SAR
• Number-of-Inputs 8
• Resolution 10 bit
• Reference-Type External, Internal
• Ratio-S-H:ADC 1899/12/30 1:01:00
• Number-of-A-D-Converters 1
• Pd-Power-Dissipation 23 mW
• Maximum-Operating-Temperature + 125 C
• Minimum-Operating-Temperature - 40 C
• Interface-Type Serial 4-Wire SPI
• SNR-Signal-to-Noise-Ratio 61.5 dB
• Gain-Error +/- 1 LSB
• Number-of-Converters 1 Converter
• Sampling-Rate 1 MS/s
• INL-Integral-Nonlinearity +/- 0.5 LSB
• DNL-Differential-Nonlinearity +/- 0.5 LSB
