HMC-ALH508 Overview

Product belongs to the HMC-ALH508G series. Type: Low Noise Amplifier Bulk is the packaging method for this product SMD/SMT Mounting-Style DIE This product's 71GHz ~ 86GHz range is 0Hz to 2.2GHz. GaAs is the technology used. Frequency Bandwidth: 71 GHz to 86 GHz Number of channels: 1 Channel Voltage Supply Range: 2.4V Supplier device package: Die This product has a 30mA of 200μA. The device offers a 13dB of 26dB. Test-Frequency is 71GHz ~ 86GHz. P1dB is 7dBm RF-Type: General Purpose Maximum operating temperature of + 85 C Minimum operating temperature: - 55 C This product operates at a 2.4 V supply voltage for reliable performance. 30 mA is 92 nA. The operating frequency is 71 GHz to 86 GHz. NF-Noise-Figure is 4.5 dB The 8 dB is 12 dB.

HMC-ALH508 Image

HMC-ALH508 Specifications

• Manufacturer Analog Devices Inc.
• Product Category RF Amplifiers
• Series HMC-ALH508G
• Type Low Noise Amplifier
• Packaging Bulk
• Mounting-Style SMD/SMT
• Package-Case DIE
• Frequency 71GHz ~ 86GHz
• Technology GaAs
• Frequency-Range 71 GHz to 86 GHz
• Number-of-Channels 1 Channel
• Voltage-Supply 2.4V
• Supplier-Device-Package Die
• Current-Supply 30mA
• Gain 13dB
• Test-Frequency 71GHz ~ 86GHz
• P1dB 7dBm
• Noise-Figure 4.5dB
• RF-Type General Purpose
• Maximum-Operating-Temperature + 85 C
• Minimum-Operating-Temperature - 55 C
• Operating-Supply-Voltage 2.4 V
• Operating-Supply-Current 30 mA
• Operating-Frequency 71 GHz to 86 GHz
• NF-Noise-Figure 4.5 dB
• P1dB-Compression-Point 7 dBm
• Input-Return-Loss 8 dB
