PTN78000AAS Overview

Product belongs to the PTN78000A series. This product is categorized as Non-Isolated / POL Type: Non-Isolated PoL Module Tray Alternate Packaging is the packaging method for this product SMD/SMT Mounting-Style Wide - 40 C to + 85 C operating temperature range for diverse applications 5-SMD Module Operational temperature range: -40°C ~ 85°C Surface Mount mounting type Versatile ITE (Commercial) applications for maximum usability Number-of-Outputs: 1 Our product delivers a 1.5A of 50mA for efficient power management. The minimum input voltage is 7V. The 28.7V. This product is designed with - voltage isolation for maximum safety and reliability. -15 ~ -3 V output voltage Input Voltage Range: 7 V to 29 V - 15 V to - 3 V output voltage for channel 1 Current output of channel 1 is 1.5 A . Surface Mount Module package-case-size

PTN78000AAS Image

PTN78000AAS Specifications

• Manufacturer Texas Instruments
• Product Category DC DC Converters
• Series PTN78000A
• Product Non-Isolated / POL
• Type Non-Isolated PoL Module
• Packaging Tray Alternate Packaging
• Mounting-Style SMD/SMT
• Operating-Temperature-Range - 40 C to + 85 C
• Package-Case 5-SMD Module
• Operating-Temperature -40°C ~ 85°C
• Mounting-Type Surface Mount
• Features OTP, UVLO
• Size-Dimension 0.75" L x 0.50" W x 0.36" H (19.1mm x 12.7mm x 9.1mm)
• Applications ITE (Commercial)
• Number-of-Outputs 1
• Current-Output-Max 1.5A
• Voltage-Input-Min 7V
• Voltage-Input-Max 28.7V
• Voltage-Isolation -
• Output-Power 9 W
• Voltage-Output-1 -15 ~ -3 V
• Voltage-Output-2 -
• Voltage-Output-3 -
• Efficiency 0.84
• Power-Watts-Manufacture-Series -
• Input-Voltage 7 V to 29 V
• Output-Voltage-Channel-1 - 15 V to - 3 V
• Output-Current-Channel-1 1.5 A
• Package-Case-Size Surface Mount Module
