| Mfr. #: | TIP105 |
|---|---|
| 제조사: | STMicroelectronics |
| 설명: | TRANS PNP DARL 60V 8A TO-220 |
| 수명 주기: | 이 제조업체의 새 제품입니다. |
| 데이터 시트: | TIP105 데이터 시트 |
Product belongs to the Darlingtons series. Tube is the packaging method for this product The TIP105_NL is listed as a Part-Aliase. Weight of 0.042823 oz Through Hole Mounting-Style TO-220-3 Through Hole mounting type Supplier device package: TO-220AB Configuration Single Transistor type: PNP - Darlington Maximum current collector Ic is 8A . Maximum collector-emitter breakdown voltage of 60V DC current gain minimum (hFE) of Ic/Vce at 2000 @ 3A, 4V. Product Attribute: Vce-Saturation-Max-Ib-Ic: 2.5V @ 80mA, 8A Power-off control: 2 W Maximum operating temperature of + 150 C Minimum operating temperature: - 65 C Rated VCEO up to - 60 V The transistor polarity is PNP. The - 60 V voltage rating is 40 V. - 5 V rating of 5 V Max DC collector current: - 8 A Minimum hfe for DC collector-base gain is 1000 at 3 A at 4 V 200 at 8 A at 4 V. - 50 uA Maximum Collector Cut-off Current;
